Characteristic description:

·Deep integration of automation, informatization, and intelligent manufacturing.

·High security, high reliability, and high operability.

·Realize integrated operations of automatic testing, automatic wire stripping, automatic assembly, automatic crimping, automatic testing, and automatic AIO visual inspection.

·Shorten debugging and delivery cycles, and quickly benefit customers.

·The system has high flexibility and the ability to quickly change models.

Technical Specifications:

·Model: DM-F2-0608

·Total length range: 150-5000mm (over 1000mm requires rolling)

·Wire diameter range: ￠ 2.8mm - ￠ 3.2mm, total stripping length 15mm

·Theoretical production capacity: 800-900pph, single station time: 4-4.5s

·The whole machine is approximately 6m (length) x 1.4m (widest point), with a height of approximately 2.3m and an area of approximately 9m2

·Workshop power supply: three-phase 380V/50HZ, single-phase 220V/50HZ, total power of about 5KW

·Supply air pressure: above 0.5Mpa;

·Weight: The overall weight of the machine is around 1.5t, and the floor is required to withstand a pressure of not less than 0.5t/m2

·Equipment excellence rate (excluding reasons for incoming material defects): ≥ 98%

·Applicable working voltage: AC220V ± 10V

·Supply air pressure: above 0.5Mpa

·Equipment noise: ≤ 72 dB
