Characteristic description:

This device can fully automate the entire process of wire cutting, wire stripping, automatic detection, twisted core wire (optional), core wire tinning (optional), terminal crimping, electrical testing, and separate receipt of finished and defective products.

Technical Specifications:

·Model: DM-F0501

·Process scope: automatic wire stripping, double ended twisted wire tinning, double ended crimping, visual inspection, automatic electrical testing

·Equipment size: 2300 * 2800 * 2200mm

·Air pressure: 0.5pa

·Power: 3KW

·Weight: Approximately 1600KG

·Wire diameter range: The wire stripping machine can produce 0.64-1.78 wire

·Wire length: Total length range of production wire (35-380mm)

·Efficiency: 900-1200pcs/H

·Equipment utilization rate: ≥ 95%

·Yield: Finished product yield ≥ 99% (measured based on original factory terminals and high-quality wire)
