Characteristic description:

This model is specially designed for cable stripping in the new energy series, which is particularly thick and requires high stripping requirements. After processing with this model, the cable stripping is neat and does not damage the inner layer. In addition, this machine has a waste collection device and an item placement device, which is very suitable for standard and process oriented production and manufacturing needs.

Technical Specifications:

·Model: DM-3030

·Operation mode: 7-inch touch screen

·Maximum stripping length: 0-300mm

·Cutting line diameter range: 3-30mm

·Peeling length setting unit: 0.01mm

·Cutting depth setting unit: 0.01mm

·Maximum number of peeling layers: 9 layers

·Number of blades: 4

·Electrical configuration: Full servo motor

·Start method: foot pedal or button start

·Archive quantity: 100 types

·Working power supply: AC220V/110V 50/60HZ

·Power: Approximately 2KW

·Dimensions: 1375 * 475 * 1365mm

·Weight: 240kg

·Production efficiency: 200-500Pcs/h (depending on the line of sight material)

·Can reserve physical interfaces for MES system docking
