Characteristic description:

This model is designed for cable stripping of special thick and high-quality requirements such as new energy charging guns, and can strip up to 1m (special customized stripping length is also available); After processing with this model, the cable stripping is neat and does not damage the inner layer, resulting in a more perfect appearance!

Technical Specifications:

·Model: DM-5010

·Maximum processing outer diameter: 10mm-45mm (wire stripping range can be customized)

·Maximum stripping length: 0-1000mm

·Cutting depth unit: 0.01mm

·Peel layer: 2 layers

·Specification: 1680mm * 680mm * 1300mm

·Weight: 380kg

·Power supply: AC220V 50 60HZ

·Power: 3Kw

·Blade: 4 pieces of imported high-speed steel

·Storage capacity: 100 types of cable processing data

·Drive mode: servo system paired with ball screw for stable output; Servo brand: Lei Sai

·Rotary cutting method: four blade cutting;

·Wire clamping method: driven by servo motor, with stable clamping force that can be set;

·Productivity: 200-400pcs/h (depending on the type and length of the line of sight cable);

·Air pressure: 0.5Pa
