Characteristic description:

This series of models is designed for the new energy series with special thickness and cable stripping requirements. After processing with this series of models, the cable stripping is neat and does not damage the inner layer. In addition, this machine has a waste collection device and an item placement device, which is very suitable for standard and process oriented production and manufacturing needs.

Technical Specifications:

·Model: DM -4520S

·Display mode: touch screen

·Applicable wires: coaxial cables, new energy cables, power cables, etc

·Cutting depth setting unit: 0.01mm

·Peeling length setting unit: 0.01mm

·Cutting line diameter range: 6-40mm

·Stripping length: 0-200mm

·Maximum number of peeling layers: 9 layers

·Display interface: Chinese and English LCD 95mm * 50mm

·Working power supply: AC220V/110V 50/60HZ

·Dimensions: 1150 * 430 * 1350

·Power: Approximately 2000W

·Peeling method: 4-piece rotating knife

·Weight: 215kg

·Drive mode: motor/ball screw drive

·Tool material: Imported tungsten steel

·Working environment: A dry and vibration free workbench at -5-45 degrees Celsius

·Storage capacity: 99 types of processing parameter data
